>>>Product Description
What is feature of 12kw 48v pure sine wave inverter mppt hybrid inverter charger with ups dc 24v to ac 220v?
1.Support Lithium/Lead-acid Battery
2.9 Inverters in Parallel
3.MAX.PV 9KW
4.Built-in 120A Solar Charger
5.Feed-in to Grid
6.Workable with Generator
7.Wide MPPT Range 120-520V
8.WiFi Monitoring
9.Lithium Battery Activation
>>>Product Specifications
| Model |
SUN-D12000-48 |
| AC Input |
| Rated Input Voltage (VAC) |
220/230/240;L+N+PE |
| Voltage Range (VAC) |
90~280±3(normal mode);170~280±3(UPS mode) |
| Frequency (Hz) |
50/60 (Auto Adaptive) |
| AC Output |
| Rated Capacity (kW) |
12 |
| Surge Power (kVA) |
24 |
| Voltage (AC) |
220 /230 / 240 |
| Power Factor |
1 |
| (PF) Frequency |
50/60Hz±0.1% |
| Switch Time (ms) |
10(APP/UPS mode), 20(GEN mode) |
| Wave Form |
Pure Sine Wave |
| Overload Capacity (Battery Mode) |
Imin@102%-125%Load;10s@>125%Load |
| Max. Efficiency (Battery Mode) |
94%@48VDC |
| Parallel Quantity |
NA |
| Charger (PV/AC) |
| Solar Charger Type |
Dual MPPT |
| Max PV input current / power |
Using One MPPT: 27A9KW, Using Two MPPTs: 22.5AVPer MPPT, 15kW/Total |
| MPPT Range@Operating Voltage (VDC) |
60~450 |
| Max PV Open Circuit Voltage (VDC) |
500 |
| Max PV Charge Current (A) |
160 |
| Max AC Charge Current (A) |
160 |
| Max. Charge Current (PV+AC)(A) |
160 |
| Battery |
| Rated Voltage (VDC) |
51.2 |
| Floating Charge Voltage (VDC) |
56 |
| Overcharge Protection (VDC) |
58.4 |
| Battery |
Lithium and Lead-acid |
| Interface |
| HMI |
LCD |
| Interface |
RS232/RS485/USB |
| Monitoring |
WiFi (optional: none/built-in/external) |
| General Data |
| Ingress Protection |
IP20 |
| Operating Temperature |
-10℃~60℃ |
| Relative Humidity |
5%-95%(Non-condensing) |
| Storage Temperature |
-15℃~60℃ |
| (NW/GW)Kg |
24.2/26.0 |
| L*W*H (products size, mm) |
425*495*132mm |
| L*W*H (package size, mm) |
551*491*191mm |
| Max.Operating Altitude |
4000m(Derating above 1000m) |
>>>Our Factory
We are a seasoned manufacturer with extensive years of experience in the production of Solar Energy
Photovoltaic Products. Our factory specializes in manufacturing a diverse range of products, including
Solar Power Inverters, AGM/GEL Lead Acid Battery Chargers, and Solar Charge Controllers, among others.
For additional details,please reach out to us at any time!
>>>FAQ
Q1. Are you the factory manufacturer?
A1. We are doing the Solar Energy Photovoltaic Products for over 20 years.
We are the original manufacturer and developer of advanced Solar Energy Photovoltaic
Product,including hybrid solar inverter, power inverter,battery chargers,solar controller,
and solar system,etc.
Q2.How to select a suitable products?
A2.Tell us your demand, we will recommend a suitable one to you.
Q3. What is your payment methods?
A3. We accept T/T,Trade Assurance,etc.
Q4. What’s the price terms can you offer for us?
A4. We can accept EXW, FOB, CIF and so on.
Q5. Where is your main market for your products?
A5. Most of our Sunchonglic brand products are exported to Southeast Asia, Africa and
Mid East etc.
Our products are widely recognized and trusted by our clients and can meet continuously
changing economic and social needs.
We would sincerely welcome new and old customers from over the world to visit and
contact us for future business relationships and mutual success!
